Features

• 12 faders
• Fully assignable layout – 72 fader strips
• Harmony UI integrates screen and wrap-around controls
• 12” capacitive touchscreen
• Gesture control – pinch, swipe, drag ‘n drop
• Dedicated multi-mode EQ view
• Configurable widget areas for Scenes, meters, FX and more
• 19 assignable SoftKeys
• Engineer’s Wedge and IEM fader strips
• Comprehensive multipoint metering
• Daylight visibility
• USB stereo recording and playback
• 6 XLR mic/line in, 6 XLR line out
• 1 digital st AES3 in, 1 digital st AES3 out
• Connection hub
• GigaACE gigabit link to MixRack
• DX link for I/O expansion
• I/O Port – 128 ch 96 kHz
• 2x Network ports
• Wordclock BNC I/O
• Video output
• Weight: 63 kg

Description

The C1500 is the first rack-mountable control Surface for the dLive MixRack. Packed in a tiny footprint are 12 faders over 6 layers, built-in audio I/O, an audio networking port, a 12″ capacitive touchscreen and the innovative Harmony UI for the fastest workflow in the industry.
