Features

• Oscillator TypeCrystal-controlled PLL synthesizer
• Reception TypeTrue diversity method
• Antenna Type1/4 λ wavelength wire antenna (angle-adjustable)
• Carrier Frequencies14UC : 470.125 MHz to 541.875 MHz(UHF-TV channels 14 to 25)
• 25UC : 536.125 MHz to 607.875 MHz (UHF-TV channels 25 to 36)
• 42LA : 638.125 MHz to 697.875 MHz(UHF-TV channels 42 to 51)
• 90UC : 941.625 MHz to 951.875 MHz, 953.000 MHz to 956.125 MHz, and 956.625 MHz to 959.625 MHz
• 21CE : 470.025 MHz to 542.000 MHz(UHF-TV channels 21 to 29)
• 33CE : 566.025 MHz to 630.000 MHz(UHF-TV channels 33 to 40)
• 42CE : 638.025 MHz to 694.000 MHz (UHF-TV channels 42 to 48)
• 38CN : 710.025 MHz to 782.000 MHz(UHF-TV channels 38 to 46)
• E : 794.125 MHz to 805.875 MHz
• BJ: 806.125 MHz to 809.750 MHz
• KR : 925.125 MHz to 937.500 MHz
• Frequency Response23 Hz to 18 kHz (Typical) (UC, U, CE, LA, CN, E, KR models)
• 40 Hz to 15 kHz (Typical) (J model)
• Signal-to-Noise Ratio60dB (1kHz sine wave, 5kHz modulation)
• Distortion (T.H.D)0.9% or less (1kHz sine wave, 5kHz modulation)
• Audio DelayApprox. 0.35 ms (analog output)
• Approx. 0.24 ms (digital output)
• Audio Output Connector3.5mm diameter 3-pole locking mini jack, external connection
• Audio Output Level-60 dBV (3.5mm diameter 3-pole locking mini jack, analog output, 0dB audio output level)
• -20 dBFS (external connection, digital output, 0dB audio output level)
• -50 dBFS (external connection, analog output, 0dB audio output level)
• Analog Audio Output Adjustment Range-12dB - +12dB (3dB step)
• Headphone Output Connector3.5mm diameter mini jack
• Headphone Output LevelMax. 10mW (16-ohm)
• Tone Signal FrequencyIn UWP-D compander mode: 32.382 kHz
• In UWP compander mode: 32 kHz
• In WL800 compander mode: 32.768 kHz
• DisplayOLED
• Power RequirementsDC 3.0 V (two LR6/AA size alkaline batteries)
• DC 5.0 V (supplied from USB Type-C connector)
• Battery Life*Approx. six hours
• *Battery life has been measured with two Sony LR6/AA size alkaline batteries at 25 °C (77 °F) DISPLAY MODE set to AUTO OFF.
• Operating Temperature0 °C to 50 °C (32 °F to 122 °F)
• Storage/Transport Temperature–20 °C to +55 °C (–4 °F to +131 °F)
• Dimensions63 × 70 × 31 mm (2 1/2 × 2 7/8 × 1 1/4 in.) (W / H / D) (excluding antenna)
• Weight: 0.1 kg

Description

The demand for high quality audio is increasing as high resolution content becomes prevalent in the video production industry. Today’s content creators are faced with the challenge of capturing high-quality audio quickly, reliably and with limited resources.
Offering superb sound quality with digital processing, reliable RF transmission, true double tuner diversity reception and friendly features, the UWP-D series is an ideal partner for ENG (electronic news gathering) and EFP (electronic field production), as well as documentaries and weddings.
High quality sound with Sony digital audio processing
NFC SYNC function for quick and easy secure channel setting
True double tuner diversity for stable signal reception
Channel memory for fast switching between two receiver frequencies
Headphone output for monitoring
Monitor mode for using a receiver as an ear monitor
Compatibility with Sony WL-800/UWP series
Output level control for receiver
High visibility OLED display, ideal for indoor/outdoor use
USB connector for power supply
