Features

• FREQUENCY RESPONSE: 35 Hz ÷ 400 Hz
• MAX SPL @ 1M: 139 dB
• WOOFER: 3 x 12'' neo, 3.0'' v.c
• INPUT CONNECTORS: XLR, RDNet Ethercon
• OUTPUT CONNECTORS: XLR, RDNet Ethercon
• CROSSOVER FREQUENCIES: Selectable
• PROTECTIONS: Thermal, RMS
• LIMITER: Fast Limiter
• CONTROLS: Gain, EQ, Preset, Phase Switch, Output Delay Settings
• RDNET: Yes
• TOTAL POWER: 3300 W Peak, 1650 W RMS
• CONNECTIONS: Powercon IN/OUT
• HEIGHT: 1100 mm / 43.31 inches
• WIDTH: 378 mm / 14.88 inches
• DEPTH: 468 mm / 18.43 inches
• Weight: 45 kg

Description

The TTL6-AS is a high power, active line source bass module engineered to deliver high output for use indoors and outdoors, for medium to large spaces. TTL 6-AS is the companion bass module for the TTL6-A, extending the frequency range of the flown system and improving the bass overall output. The TTL6-AS bass module is equipped with 3 x 12” low frequencies woofers in bass reflex configuration. The integration of three channels of digital amplification and the advanced digital processing set a new standard for distortion, noise and thermal efficiency.
